AT Standard Type

· Vertical direct pressure mold clamping, vertical injection. The lower die is fixed and the upper die moves.

· The clamping force is 35-1200 tons, and the injection volume is 1-6000g.

· Two-plate press can provide 450-2300 tons of clamping force.

-------------------------------------------------------

·High rigidity template, the lower die is fixed, the upper die is movable, and the parallel accuracy is less than 0.05mm. Good positioning for embedded items, no need to worry about embedded items shifting.

·Mold clamping adopts direct pressure clamping structure, stress distribution is even, quick clamping and slow low pressure clamping operate smoothly throughout the whole process, which effectively protects mold and personal safety.

-------------------------------------------------------

injection unit

·Modular design, can be equipped with different speed/pressure injection components; meet the specialized needs of different products.

·Self-developed screw structure, using imported powder alloy steel, the whole round bar is quenched and tempered at high temperature, the hardness reaches HRC60°, combined with different types of fine and rough grinding processes, the concentricity of the bottom diameter and the outer diameter reaches 0.03mm, reaching various The high precision required by the product increases the service life of the screw in different environments.

-------------------------------------------------------

Diversified oil circuit system

·Diversified oil circuit system design adapts to the optimization of oil circuits of different tonnage sizes. With AGCO's self-developed oil circuit board structure and the latest Yuken control valve, the power and energy efficiency transfer is smooth and the machine moves smoothly.

·For higher precision control, the oil circuit can be upgraded to oil circuit system closed-loop and AGCO Loop injection closed-loop to meet the diverse requirements of customers.

-------------------------------------------------------New generation control system

·Multi-PID control for different control objects and operating conditions, the control is more accurate and efficient; The power system integration based on EtherCAT bus has high signal precision and strong anti-interference ability; The latest OPC UA communication protocol can be extended, and it is fully compatible with the latest international and domestic A new generation of intelligent algorithms for communication standards can effectively sense process deviations and hedge them in real time to ensure the stability of process results.

·Combination of centralized control and edge computing, modular control of key functions, good system flexibility, extensibility, tailoring, taking into account general performance and flexibility; New dynamic temperature control algorithm.

------------------------------------------------------

·Scroll down to see more pictures of the AT series.
