AT-Standard

AT standard series

· Vertical direct pressure mold clamping, vertical injection. The lower die is fixed and the upper die moves.

· The clamping force is 35-1200 tons, and the injection volume is 1-6000g.

· Two-plate press can provide 450-2300 tons of clamping force.

----------------------------------------------------------------

·High rigidity template, the lower die is fixed, the upper die is movable, and the parallel accuracy is less than 0.05mm. Good positioning for embedded items, no need to worry about embedded items shifting.

·Mold clamping adopts direct pressure clamping structure, stress distribution is even, quick clamping and slow low pressure clamping operate smoothly throughout the whole process, which effectively protects mold and personal safety.

----------------------------------------------------------------

injection unit

·Modular design, can be equipped with different speed/pressure injection components; meet the specialized needs of different products.

·Self-developed screw structure, using imported powder alloy steel, the whole round bar is quenched and tempered at high temperature, the hardness reaches HRC60°, combined with different types of fine and rough grinding processes, the concentricity of the bottom diameter and the outer diameter reaches 0.03mm, reaching various The high precision required by the product increases the service life of the screw in different environments.
