AT-Sliding

AT-Sliding Type

·Vertical clamping, vertical injection, clamping force 35-1200 tons, injection volume 100-6000g;

·The sliding plate and bottom plate are made of ductile iron, the connecting parts are isolated by steel belts, and there are lubricating oil holes, which greatly reduces the wear of the sliding plate, the deformation is small, and the service life and accuracy of the sliding plate are increased.

·Ejector pin can be used with different slides, and can freely adjust the stroke, demoulding force, thimble advancing and retreating speed and demoulding times can also be preset according to needs.

·Single-mode sliding plate, using front and rear (or left and right) reciprocating single-mode sliding plate, the embedded device and the external operation of the extraction device, the operation safety is high.

·Diversified oil circuit system design (semi-closed, fully-closed, servo or high-speed injection molding) can meet customer needs, and expandable programming design can be connected with automatic embedding and extraction equipment to achieve fully automatic operation.

·It can meet customer needs, expandable design, and connect with automatic embedding and extraction equipment to achieve fully automatic production.

·Double slides, using two molds to slide left and right alternately, one mold is formed, and the other mold is embedded in the outside, which has high operation safety and can increase production efficiency by 50%.

·Using four-column direct pressure clamping structure, four-column synchronous clamping, the parallelism of clamping is less than 0.1mm, innovative use of forging machine column, stable clamping for up to 20 years, the maximum clamping force can reach 8000KN.

·Modular design, can be matched with different power injection units according to customer needs.

·Personalized movable operation panel, automation integrated equipment can be placed around the equipment, and the operation is more convenient.

·Safety: Fully enclosed safety shield. Independent electric control boxes for high-voltage electrical components and low-voltage electrical components, and an emergency stop button behind the equipment to ensure safe operation.
